TT73 – contacts for higher currents

With the same outer diameter as the TT93-Kontakt, the turned TT73 wins points by having a substantially higher current carrying capacity of up to 30 A. Because of spatial proximity, the standard housings can be very easily adapted to the TT73 contact.

Technische Spezifikationen

material Copper alloy/high-grade steel
acceptable current load 30A at +68°F in free air
contact resistance <3 mΩ (< 7 mΩ after 1000 Connection cycles)
insertion/withdrawal force <3N
connection cycles min 1000
show drawing
close
Nummernschlüssel für TT73 (Zum Vergrößern klicken)
click to enlarge
